Steel Windbreak & Dust Suppression Fence Wall
The wind fence system is a customized coal dust control solution for thermal power plants and coal storage yards.We provide a series of windbreak fencing systems for wind reduction or dust control purposes in industries such as mining, agricultural, power generation, transportation, construction sites.civil works, land development, etc. All our wind fences are customized according to the wind speed, wind pressure, geological conditions, climate conditions, etc.
Working Principle
Wind break and dust suppression wall is a porous barrier. At the back of the wall, a low-velocity zone is formed. It effectively reduces the average wind speed, thereby prevents dust from moving, and achieves the purpose of dust suppression.
Construction
The steel windbreak fencing consists of three parts: the foundation, steel structure and the steel windbreak panel. The steel structure is custom designed according to factors such as the coal pile height, wind load, desired earthquake resistance, etc. Each structural post for our coal pile wind fence is completed in factory. The steel windbreak panels are fastened on the structure by stainless bolts and nuts.
The fence connectors are punched from the same material as the fence panels, and also comes the same surface treatment. Two steel windbreak panels are connected together with panel connectors on the long edge.
All the bolts and nuts used in the wind break system are all fabricated from stainless steel. The wind fence panels are connected to the steel structure by bolts and nuts. The panel connector is also fastened by bolts and nuts.
The steel wind barrier is typically built along the border of coal storage yard in proper positions.
Specifications
Peak height 75-80mm
Aperture ratio 30%-50%
Length: Max. 6m
Peak Type | Specifications | Aperture Opening Rate (%) | Aperture Diameter (mm) | |||
Model | Length (mm) | Width (mm) | Thick- ness (mm) |
|||
Single Peak | WF-01 | 4000~6000 | 250~500 | 0.5~1.5 | 30~50 | 13mm, 30mm |
Double Peak | WF-02 | 4000~6000 | 400~600 | 0.5~1.5 | 30~50 | 13mm, 30mm |
Triple Peak | WF-03 | 4000~6000 | 810~950 | 0.5~1.5 | 30~50 | 13mm, 30mm |
Materials
Aluminum plate, galvanized steel plate, stainless steel sheet, polymer resin-based composite materials, carbon fiber reinforced polymer composite materials
Color of the metal fencing panel can be selected by the user so as to match the surrounding environment. Multi-color collocation makes the wind fence system a beautiful scene.
Surface Treatment: Electrostatic powder spray.
Usage
Wind break and dust suppression wall is an advanced technology to solve the problem of dust pollution in the open yard of bulk material. It is widely used in port terminals, thermal power plants, coal mines, coal washing plants, coking plants, iron and steel enterprises, cement plants, and other business field which has the problem of dust pollution. Using the principle of aerodynamic, wind, which is the source of the dust, is effectively controlled. So that it can achieve the maximum attenuation of the wind kinetic energy, reduce the dust arousing and carrying capacity of wind and achieve the effect of dust suppression, Dust suppression rate can be much more than 80%. At present, it has been one major dust pollution control technology being applied.
Wind break and dust suppression wall can also be applied to control dust in desert areas, highways, high-speed railway embankment protection, and provision of micro-climate for crops.
Performance Evaluation
* Reduce the material losses in open yard
* Save the water for dust suppression
* Improve the living conditions of nearby residents
* Improve the working conditions of the on-site staff
* Reduce the dust pollution to the surrounding air and water
