Drag Mats For Turf & Infield
Drags, Drag mats, Drag Screen, Golf Course Drag Mats, Flexible Turf Drag, Softball & Baseball Diamond Drag Mats, Drag Mats For Sports Fields Or Turf Preparation, Flexible Steel Drag Mats, Steel Mat Drags, Flexible Metal Drag Mats, Steel Mats, Door Mats, Flexible Door Mats, Metal Door Mats, Flexible Steel Floor Mat
If steel is so hard, how can it be flexible? Through the use of a continuous pattern of interlocked cold-rolled steel rods and strips.
Flexible Turf & Infield Drag Mats-Standard Duty
Flexible Steel Drag Mats are used on baseball diamonds, sand traps on golf courses or any other sports field application where you need dirt, gravel or sand perfectly leveled out. The other very common use for a drag mat is to prepare soil before laying sod, hydroseeding, construction, or regular grass seeding. Save yourself or your employees many, many hours of back breaking raking. Attach to a utility vehicle such as a Gator and simply pull the mat off the soil and you will have a perfectly level area when completed.
The Standard Mat rolls up like a carpet for easy cleaning and offers a smooth level rugged surface. It is very good for assembly lines around oily machine areas and as an outdoor entrance scraper mat. Each type is available with pull attachments for drag mat work and both feature a galvanized finish for increased rust resistance.
Available sizes of flexible steel drag mats: 3’x3’, 3’x4’, 3’x5’, 4'x 5', 5'x 3', 6'x 3', 6’x4’, 6’x6’, 8’x6’,10’x6’. The first number is the working width of the drag mat. Made of galvanized steel or stainless steel.
Flexible Turf & Infield Drag Mats-Heavy Duty
The Heavy Duty Mat offers three times the strength of the flexible turf drag. 1/2”x .062” thick crimp, with a 1” x 1” galvanized mesh. 3.5 lbs. per sq. ft.weight. Comes complete with steel drag attachment with forged eye bolts. (Tow chain sold separately.)
It is perfect for breaking up plugs on golf course fairways, dragging baseball infields or track surfaces, and for soil preparation for lawn seeding.
Available sizes of flexible steel drag mats: 4'x 4', 6’x4’, 6’x6’, 8’x6’. The first number is the working width of the drag mat. Made of galvanized steel or stainless steel.
|Heavy Duty Mats||Standard-Duty Mats|
|Thickness||1/2" (12.7mm)||3/8" (9.5mm)|
|Weight||3.5# per Square Foot||1.6# per Square Foot|
|Mesh Size||1"x1" (25mmx25mm)||1"x1" (25mmx25mm)|
|Crimp||1/2"x .062" galvanized steel (12.7mmx1.57mm)||
3/8"x.046" galvanized steel
6 gage (.192") galvanized steel
13 gage (.0915") galvanized steel
|Edge||Button head weld|
|Color||Steel Grey||Steel Grey|
Rigid Drag Mats
Rejuvenate your ball field and eliminate the wear and tear of cleats and traffic with the smoothing touch of the Rigid Drag Mat.
This is an extremely rigid mat with mesh rotated 90 degrees to maximize its effectiveness in smoothing uneven surfaces. Comes with heavy-duty angle iron across front of mat, as well as a rope and handle for pulling.
Not able to be rolled up for storage.
Mesh size 1" x 1"
Crimp 3/8" x .046" Galvanized Steel
Rods 13 Gauge (.0915" Dia) Galvanized Steel
