Press Locked Steel Bar Grating Fences, Perimeter High Security Fence Grates Guard for Prison

China Press Locked Steel Bar Grating Fences, Perimeter High Security Fence Grates Guard for Prison supplier
Press Locked Steel Bar Grating Fences, Perimeter High Security Fence Grates Guard for Prison supplier Press Locked Steel Bar Grating Fences, Perimeter High Security Fence Grates Guard for Prison supplier Press Locked Steel Bar Grating Fences, Perimeter High Security Fence Grates Guard for Prison supplier

Large Image :  Press Locked Steel Bar Grating Fences, Perimeter High Security Fence Grates Guard for Prison

Product Details:

Place of Origin: CHINA
Brand Name: GEYE
Model Number: PRESS LOCK BAR GRATING FENCES

Payment & Shipping Terms:

Packaging Details: PALLET
Delivery Time: 20 DAYS
Payment Terms: L/C, T/T, Western Union
Contact Now
Detailed Product Description

Steel Grating Fences Press locked are a smart, robust and affordable form of perimeter protection. They provide excellent resistance to vandalism, combined with a stylish modern appearance when used in the garden, on the building site or as a crowd barrier in football stadiums.



Different mesh spacing options permit different fence designs.
Cross bar spacing (F)

66,6 (P) 66,6 99,9 133,2

44,4 (P) 44,4 88,8 133,2

Bearing bars optionally: 25 x 2 or 25 x 3

Cross bar: 10 x 2 mm

Banding bar: 25 x 4 mm

Posts dimensions: 60 x 8 mm and 80 x 8 mm



It is also part of our service to supply all the right accessories to the fence gratings such as posts and fastening screws. Assembling the fence couldn't be easier. The individual elements are simply screwed together by means of screws and counter nuts.

Press Locked Steel Bar Grating Fences, Perimeter High Security Fence Grates Guard for Prison

Standard fastening



To fasten the fence elements to the posts, we recommended high-grade steel screws the following sizes:

M 10 x 25 for hot-dip galvanised fencing

M 10 x 30 and two high-grade steel washers for the painted fences



Extra secure fastening



The special screw nut consist of a curved bottom part and of a smooth hexagonal head which scales off during the tightening process.

TT M 10 x 25

Press Locked Steel Bar Grating Fences, Perimeter High Security Fence Grates Guard for Prison

Common Applications

  • Medium security
  • Business parks
  • Commercial and prestigious
  • Schools and colleges
  • Playgrounds, parks & recreation
  • Housing developments
