Wedge Wire Screen Support Grids For Supporting Media In Vessels And Tanks

Support grids provide superior media retention characteristics in vessels of all types. They feature durable construction, precise open area, and are virtually non-clogging. For larger vessel diameters our support grids are manufactured in sections to accommodate installation through man ways. A complete vessel internal design includes inlet basket, distributor laterals, support grid, outlet basket, collector laterals with backwash systems for efficient and effective operations.

Flat Wedge Wire support grids offer a relatively flat and smooth surface to reduce degradation of the media in down-flow processes. The high open area of the Wedge Wire screen provides excellent capacity.

Stainless steel wedge wire support grids can be designed for total load and operating temperature. The all-welded stainless steel construction produces high strength and extended service life suitable for many screening applications in numerous industries. Support grids are used in carbon filters, desulfurizers, molecular sieves, sand filters, gas sweeteners and lauter tanks.

Wedge Wire screen offers continuous slot openings that widen inwardly so that particles tend to pass through the screen.
