Tin Plated Copper Wires Knitted Mesh Conductive Tapes, Tubular Knitted Tinned Copper Mesh for EMI RFI Shielding

China Tin Plated Copper Wires Knitted Mesh Conductive Tapes, Tubular Knitted Tinned Copper Mesh for EMI RFI Shielding supplier
Tin Plated Copper Wires Knitted Mesh Conductive Tapes, Tubular Knitted Tinned Copper Mesh for EMI RFI Shielding supplier Tin Plated Copper Wires Knitted Mesh Conductive Tapes, Tubular Knitted Tinned Copper Mesh for EMI RFI Shielding supplier Tin Plated Copper Wires Knitted Mesh Conductive Tapes, Tubular Knitted Tinned Copper Mesh for EMI RFI Shielding supplier Tin Plated Copper Wires Knitted Mesh Conductive Tapes, Tubular Knitted Tinned Copper Mesh for EMI RFI Shielding supplier

Large Image :  Tin Plated Copper Wires Knitted Mesh Conductive Tapes, Tubular Knitted Tinned Copper Mesh for EMI RFI Shielding

Product Details:

Place of Origin: CHINA
Brand Name: GEYE
Model Number: TINNED COPPER KNITTED TAPES

Payment & Shipping Terms:

Packaging Details: CARTONS
Delivery Time: 20 DAYS
Payment Terms: L/C, T/T, Western Union
Contact Now
Detailed Product Description

TINNED KNITTED COPPER MESH



This conductive tape is manufactured by knitting one or several tin plated wires. This is a remarkable product to overlap equipotential bonding when it is not possible to disconnect cables and to install tubular braid. Knitted wire mesh tape is also suitable for EMI shielding. According to the number of layers overlapped, it can provide up to 80dB shielding effectiveness.



CHARACTERISTICS

Tubular knitted mesh, flat shape dual wall for EMI shielding

Tin Plated Copper Wires Knitted Mesh Conductive Tapes, Tubular Knitted Tinned Copper Mesh for EMI RFI Shielding

COMPOSITION

Different widths made of one or several tin plated copper wires



STANDARDS

Copper wires in accordance with NF EN 13602



APPLICATIONS

4 layers spiral wounded with 30% to more than 50% overlap can reach 80dB shielding effectiveness.

Knitted tape can be used as shield connection in branch joints, light grounding.

Tin plated copper type provides verry good weldability

Tin Plated Copper Wires Knitted Mesh Conductive Tapes, Tubular Knitted Tinned Copper Mesh for EMI RFI Shielding

VARIANTS

Other materials upon request

Other widths upon request

Adhesive tape optional



PACKAGING

Rolls, cut lengths upon request
