| Features: | High Strength, Corrosion Resistance | Length: | 100m To 240m Depending Upon Customer Requirement |
|---|---|---|---|
| Installation Method: | Wrapped Around The Pipe | Coating Type: | Galvanized |
| Corrosion Resistance: | High | Thickness Of Hot Dip Galvanizing Coating: | Up To 300g/m2 |
| Wire Diameter: | 1.6×1.6mm, 2.0×2.0mm, 2.3×2.0mm, 2.6×2.0mm, Customized Specification | Usage: | Oil And Gas Pipelines, Reinforcement For Steel Pipe Which Will Be Coated With Concrete And Then Submerged In Water Or Earth |
The Wire Mesh for Pipe Coating is a premium product designed to meet the rigorous needs of the oil and gas industry. Specifically fabricated for use in reinforcing steel pipes that are destined for concrete coating and subsequent submersion in water or earth, this mesh ensures structural integrity and longevity of pipelines. Its primary applications include the reinforcement of pipes for oil and gas pipelines, where it serves as an essential component in maintaining the pipeline's durability and reliability.
Built to withstand the harsh environments typically associated with oil and gas pipeline installations, this Wire Mesh for Pipe Coating offers high corrosion resistance. The longevity of pipelines is a critical concern in such applications, and this mesh is engineered to resist the corrosive effects of the elements and the materials that they come into contact with. Its high corrosion resistance is achieved through a substantial thickness of hot dip galvanizing coating, which can be up to 300g/m2, providing an enduring barrier against rust and degradation.
The mesh size options available with this product are 67×25.4mm, 67×50.8mm, and 92.3×25.4mm, which have been determined to offer optimal performance in a variety of pipe coating applications. The choice of mesh size is crucial, as it affects the adherence of the concrete to the pipe as well as the overall strength of the reinforced structure. These sizes ensure that the mesh can provide the necessary support without compromising the integrity of the concrete coating.
Our Wire Mesh for Pipe Coating is available in several wire diameters, including 1.6×1.6mm, 2.0×2.0mm, 2.3×2.0mm, and 2.6×2.0mm. We understand that each project has unique requirements, which is why we also provide customized specifications to ensure that your specific needs are met. The wire diameter contributes to the overall strength and weight of the mesh, allowing for tailored reinforcement solutions that align with the engineering demands of the pipelines.
Recognized as a Welded Mesh for Concrete Weight-Coated Pipeline, this product is essential in the construction of pipelines that require additional weight to ensure stability and to prevent buoyancy when submerged. This type of mesh is integral to the weight-coating process, where it acts as a skeleton to which the concrete adheres, adding the necessary weight and protection to the pipeline.
Furthermore, the Wire Mesh for Pipe Coating is also known as Offshore Pipeline Counterweight Welded Mesh, highlighting its significance in offshore pipeline projects. The mesh serves as a counterweight to ensure that pipelines remain anchored at the seabed, despite the dynamic and challenging conditions found in offshore environments. Its robust construction and corrosion resistance make it an ideal choice for such critical applications.
This product also finds its use as Reinforced Welded Mesh, providing additional strength to pipelines that require a high level of structural reinforcement. Whether for onshore or offshore applications, this wire mesh plays a vital role in ensuring the safety and efficacy of the pipelines it supports. By preventing structural deformities and maintaining the pipe's shape under the pressure of the concrete coating and the external environment, this mesh ensures the pipelines' operational integrity.
In conclusion, the Wire Mesh for Pipe Coating is an indispensable product for the oil and gas industry, offering unparalleled corrosion resistance, a range of mesh sizes and wire diameters, and a high degree of customization to meet the unique demands of every project. Whether used for onshore or offshore pipelines, as a welded mesh for concrete weight-coated pipelines, or as an offshore pipeline counterweight, this reinforced welded mesh stands as a testament to our commitment to quality, durability, and reliability.
| Parameter | Description |
|---|---|
| Wire Diameter | 1.6×1.6mm, 2.0×2.0mm, 2.3×2.0mm, 2.6×2.0mm, Customized Specification |
| Width | 190.5mm/241.3mm |
| Length | 100m To 240m Depending Upon Customer Requirement |
| Thickness of hot dip galvanizing coating | Up To 300g/m2 |
| Installation Method | Wrapped Around The Pipe |
| Mesh Size | 67×25.4mm, 67×50.8mm, 92.3×25.4mm |
| Usage | Oil And Gas Pipelines, Reinforcement For Steel Pipe Which Will Be Coated With Concrete And Then Submerged In Water Or Earth |
| Features | High Strength, Corrosion Resistance |
| Material | Galvanized Steel |
| Corrosion Resistance | High |
Brand IDECO has established a strong presence in the pipeline construction industry with its Welded Wire Mesh for Concrete Pipe Coating, reflecting a commitment to quality and durability. This product is expertly manufactured in CHINA and boasts the prestigious ISO 9001 certification, ensuring that it meets the highest standards of quality. IDECO's Welded Wire Mesh is designed with specific applications in mind, particularly serving as a reinforcement mesh for pipes that require an Outer Cement Coating Of Pipes for additional protection and stability.
With a robust supply ability of 300 km per month, IDECO ensures that project demands are met promptly, offering a delivery time of 7-20 days. The flexibility of the Minimum Order Quantity being unlimited allows clients to order according to their project scale without restriction. Packaging is efficiently handled in bundles, providing ease of transportation and storage. To accommodate various business needs, IDECO accepts a range of payment terms, including L/C, T/T, and Western Union.
The Weld Mesh Fixing for pipeline applications is a testament to IDECO's innovation in product application scenarios. This mesh is essential for oil and gas pipelines, where it provides an essential layer of reinforcement for steel pipes. The pipes, once coated with concrete, can be safely submerged in water or earth, thanks to the high-strength and corrosion resistance features of the wire mesh. The galvanized coating type further enhances its durability and longevity under harsh environmental conditions.
The Pipe-coating Wire Mesh is available in mesh sizes of 67×25.4mm, 67×50.8mm, and 92.3×25.4mm, with widths of 190.5mm and 241.3mm to suit a variety of pipe diameters. These dimensions make the IDECO wire mesh adaptable for various pipeline projects, ensuring that the pipes are securely coated and reinforced for their intended use. Whether it's a small-scale local project or a large-scale industrial endeavor, IDECO's Welded Wire Mesh for Concrete Pipe Coating is the preferred choice for professionals who seek reliability and efficiency in their pipeline infrastructure.
Brand Name: IDECO
Model Number: Welded Wire Mesh for Concrete Pipe Coating
Place of Origin: CHINA
Certification: ISO 9001
Minimum Order Quantity: Unlimited
Packaging Details: BUNDLE
Delivery Time: 7-20 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 300 km per month
Mesh Size: 67×25.4mm, 67×50.8mm, 92.3×25.4mm
Wire Diameter: 1.6×1.6mm, 2.0×2.0mm, 2.3×2.0mm, 2.6×2.0mm, Customized Specification
Coating Type: Galvanized
Usage: Ideal for Oil and Gas Pipelines, serving as Reinforcement for Steel Pipe which will be coated with concrete and then submerged in water or earth. Also suitable as Welded Mesh For Concrete Weight-Coated Pipeline and Offshore Pipeline Counterweight Welded Mesh.
Installation Method: Conveniently Wrapped Around The Pipe for easy application.
Our Wire Mesh for Pipe Coating products are backed by comprehensive technical support and services designed to ensure the highest level of performance and customer satisfaction. From product selection to application assistance, our team of experts is available to guide you through the process of utilizing our wire mesh for your pipe coating needs. We provide detailed product specifications, installation guidelines, and best practices to maximize the effectiveness of our wire mesh.
In addition to offering support prior to purchase, we are committed to providing ongoing services post-installation. Our technical support includes troubleshooting assistance, performance evaluation, and recommendations for maintenance to extend the life of our wire mesh products. Our goal is to help you achieve optimal results in your pipe coating applications and to address any concerns that may arise during the lifecycle of the product.
For any technical inquiries or service requests regarding our Wire Mesh for Pipe Coating, please reach out to our dedicated support team. We are here to assist you with any questions or challenges you may face, ensuring that your experience with our product is both effective and satisfying.
The Wire Mesh for Pipe Coating product is meticulously packaged to ensure its integrity and quality during transit. Each roll of wire mesh is securely wrapped in a protective layer to guard against moisture, dust, and mechanical damage. The wrapped rolls are then placed in sturdy, corrugated cardboard boxes, which are sealed and reinforced with heavy-duty packing tape for additional security.
For larger orders, the boxed wire mesh rolls are further arranged onto wooden pallets, which are then shrink-wrapped to provide stability and prevent any movement during shipping. The pallets are clearly labeled with the necessary shipping and handling instructions to guarantee safe transportation to their destination.
Prior to dispatch, all packages are inspected to ensure they meet our strict packaging standards. We also include a detailed packing list with each shipment, allowing recipients to easily verify the contents upon arrival. Our shipping partners are chosen for their reliability and experience in handling industrial materials, ensuring that your Wire Mesh for Pipe Coating arrives on time and in perfect condition.
