Home ProductsDrags Mats & Harrows

Hot-dipped Galvanized Steel Drag Mats for Tennis Court/ Baseball/Soccer Field/Playground,Clay Mats,Sand Drag Mats

Good quality Refractory Anchors for sales
Good quality Refractory Anchors for sales
Hi April, Yes we already send it to our user and no complain :-) Thank you for your support Sure will send you an email for another inquiry

—— Fellycia

I'm Online Chat Now

Hot-dipped Galvanized Steel Drag Mats for Tennis Court/ Baseball/Soccer Field/Playground,Clay Mats,Sand Drag Mats

China Hot-dipped Galvanized Steel Drag Mats for Tennis Court/ Baseball/Soccer Field/Playground,Clay Mats,Sand Drag Mats supplier
Hot-dipped Galvanized Steel Drag Mats for Tennis Court/ Baseball/Soccer Field/Playground,Clay Mats,Sand Drag Mats supplier Hot-dipped Galvanized Steel Drag Mats for Tennis Court/ Baseball/Soccer Field/Playground,Clay Mats,Sand Drag Mats supplier Hot-dipped Galvanized Steel Drag Mats for Tennis Court/ Baseball/Soccer Field/Playground,Clay Mats,Sand Drag Mats supplier Hot-dipped Galvanized Steel Drag Mats for Tennis Court/ Baseball/Soccer Field/Playground,Clay Mats,Sand Drag Mats supplier

Large Image :  Hot-dipped Galvanized Steel Drag Mats for Tennis Court/ Baseball/Soccer Field/Playground,Clay Mats,Sand Drag Mats

Product Details:

Place of Origin: CHINA
Brand Name: GEYE
Model Number: HDG DRAG MAT

Payment & Shipping Terms:

Packaging Details: ROLLS
Delivery Time: 15 DAYS
Payment Terms: L/C, T/T, Western Union
Contact Now
Detailed Product Description

Steel Drag Mats



Drag mats are used on baseball diamonds, sand traps on golf courses or any other sports field application where you need dirt, gravel or sand perfectly leveled out. The other very common use for a drag mat is to prepare soil before laying sod, hydro-seeding, construction, or regular grass seeding. Save yourself or your employees many, many hours of back breaking raking. Attach to a utility vehicle such as a Gator and simply pull the mat off the soil and you will have a perfectly level area when completed.



Our drag mats are with very high quality, flexible and weighted to make the task easy. The drag mats have a unique clinch to reduce snags and a rivet free u-bar that holds the mat firmly flat on the surface. There is a heavy nylon rope or tow chains tied to the bar on the drag mat that can be pulled by a vehicle or if needed by a person. There is no top or bottom, so this makes the mats easy to use and requires very little employee training.



Smooth out rough surfaces quickly with these very high quality and durable drag mats.

Hot-dipped Galvanized Steel Drag Mats for Tennis Court/ Baseball/Soccer Field/Playground,Clay Mats,Sand Drag Mats

Standard Duty Mats

3/8" (9.5mm) deep x .05" (1.27mm) thick crimp with 1"x 1" mesh, 13 gauge(2.3mm) connecting rods, 1.6 lbs. per sq.ft. weight.



Comes completely with a nylon rope and handle attached. It is perfect for grooming and general field maintenance!



Specification

Part # W x L Equipped Weight
SDMAT33 3'W x 3'L w/Drag Bar & Rope (w/grip) 17lbs
SDMAT34 3’W x 4’L w/Drag Bar & Rope (w/grip) 23lbs
SDMAT35 3'W x 5'L w/Drag Bar & Rope (w/grip) 28lbs
SDMAT45 4'W x 5'L w/Drag Bar & Rope (w/grip) 34lbs
SDMAT46 4’W x 6’L w/Drag Bar & Rope (w/grip) 42lbs
SDMAT55 5’W x5’L w/Drag Bar & Rope (w/grip) 46lbs
SDMAT63 6'W x 3'L w/Drag Bar & Rope (w/grip) 35lbs
SDMAT64 6’W x 4’L w/Drag Bar & Rope (w/grip) 42lbs
SDMAT66 6'W x 6'L w/Drag Bar & Rope (w/grip) 64lbs
SDMAT83 8’W x 3’L w/Drag Bar & Rope (w/grip) 45lbs
SDMAT86 8'W x 6'L w/Drag Bar & Rope (w/grip) 84lbs
SDMAT88 8’W x 8’L w/Drag Bar & Rope (w/grip) 110lbs
SDMAT104 10’W x 4’L w/Drag Bar & Rope (w/grip) 72lbs
SDMAT106 10’W x 6’L w/Drag Bar & Rope (w/grip) 97lbs
SDMAT126 12’W x 6’L w/Drag Bar & Rope (w/grip) 125lbs


Remark: Special specs may be made according to customers' special requirements.



Heavy Duty Mats

1/2” (12.7mm) deep x .062” (1.57mm) thick crimp with 1" x 1" mesh, 6 gauge(4.9mm) connecting rods, 3.5 lbs. per sq.ft. weight. each welded on end. Mat cannot separate!



Comes completely with a steel angle with eye bolts attached for you to attach your chain.

(Tow Chain Optional) (chain assembly sold separately) This mat will last for many years!



Specification

Part # W x L Equipped Weight
HDMAT44 4'W x 4'L w/Drag Bar & Tow Chain 61lbs
HDMAT64 6'W x 4'L w/Drag Bar & Tow Chain 94lbs
HDMAT66 6'W x 6'L w/Drag Bar & Tow Chain 128lbs
HDMAT86 8'W x 6'L w/Drag Bar & Tow Chain 184lbs


Remark: Special specs may be made according to customers' special requirements.

Hot-dipped Galvanized Steel Drag Mats for Tennis Court/ Baseball/Soccer Field/Playground,Clay Mats,Sand Drag Mats

Rigid Steel Drag Mats

With 1" x 1" mesh, 13 gauge galvanized connecting rods. Mesh material is 3/8"(9.5mm) x .05” (1.27mm) galvanized steel.



Same as Standard Drag Mat except mesh has been rotated 90 degrees to make mat rigid which helps maximize its effectiveness to smooth out uneven surfaces. Rigid Mats can NOT be rolled up for storage.



Includes heavy-duty angle iron across front of mat and a rope and handle for pulling.



Specification

Part # W x L Equipped Weight
RDMAT418 4'W x 18"L Rigid w/Drag Bar&Rope(w/grip) 24lbs
RDMAT4X2 4’W x 2’L Rigid w/Drag Bar&Rope(w/grip) 28lbs
RDMAT4X3 4’W x 3’L Rigid w/Drag Bar&Rope(w/grip) 33lbs
RDMAT618 6'W x 18"L Rigid w/Drag Bar&Rope(w/grip) 35lbs
RDMAT6X2 6’W x 2’L Rigid w/Drag Bar&Rope(w/grip) 38lbs
RDMAT6X3 6’W x 3’L Rigid w/Drag Bar&Rope(w/grip) 44lbs


Remark: Special specs may be made according to customers' special requirements.
